Specifications:
Honing Diameter | Min 20 mm, Max 135 mm |
Honing Length Max | 1650 mm |
Head stroke Max | 1850mm |
Max. Tube (work Piece) Length | 1650 mm |
Spindle Column distance | 370mm |
Rotation spindle Speed (RPM) Range | 40-120r/min |
Head stroke Speed (m/min) Range | 5-20m/min |
Rotation Spindle Motor | 5.5kw |
Vertical Movement Head Motor | 7.5kw |
Coolant Pump Motor | 0.37KW |
Machine Height | 4900mm |
Machine Weight | 4000kg |
